Electric pallet stacker W10 INOX

W10 INOX is made of AISI 304 stainless steel, ideal for handling pharmaceutical, chemical and food goods.

Electric pallet stacker W10 INOX

W10 INOX is made of AISI 304 stainless steel, ideal for handling pharmaceutical, chemical and food goods.

Electric pallet stacker W12

Main features

electric pallet stacker with cold store

1000 kg

Max lifting capacity

2-3 hours

Autonomy

Schuko plug

Schuko charging cable

electric pallet trucks and pallet stackers

Battery indicator

Schuko plug

Schuko charging cable

electric pallet trucks and pallet stackers

Battery indicator

Stainless Steel Forklift

Stainless steel AISI 304

Easy water jet cleaning

Easy water jet cleaning

Electric stainless steel pallet stacker W10

FEATURES

Ideal for handling medical and food goods.

W10 INOX is the pallet stacker made of AISI 304 stainless steel, ideal for handling pharmaceutical, chemical and food goods. It is supplied with IP56 protection grade for easy water jet cleaning.

Technical specifications

Guide with lateral rudder, controlled by man on the ground.

Electronic system MOSFET 24V 90A.

Proportional control of the forks descent speed.

Speed selector for manoeuvres with vertical rudder.

Suitable for use in cold store -30 ° C.

LCD meter connected to the microrudder

Mast protection in stainless steel mesh.

Drive wheel ring in soft anti-trace polyurethane with sculpted tread.

Components compartment bonnet (electronic system, hydraulic control unit, rectifier, batteries) in stainless steel AISI304 with IP56 protection.

Control head with IP56 protection.

Single front roller in nylon covered with polyurethane with bearings in stainless steel AISI304.

Single lifting cylinder in stainless steel AISI304.

Drive wheel with IP56 protection in aluminum anticorrosion with motor protections and electromagnetic brake in stainless steel AISI304.

Packaging on wooden pallets

Electronic system MOSFET 24V 90A.

24V 2200W Hydraulic power unit with up/down solenoid valve and emergency manual descent.

Built-in 24V 10A high frequency battery charger.

Drive motor with permanent magnets system up to 24V 700W complete of electromagnetic brake.

Battery charge indicator with low battery lock.

Models

Electric pallet stacker W12

MODELS

W12 standard

The W10 Inox pallet stacker is available in the version with lifting capacity 1000 kg

Customize your pallet stacker W12

MODELS

Also available in standard version

The W12 pallet stacker is also available in the standard version with 1200kg capacity.

Electric pallet stacker W12
w10 inox electric pallet stacker in stainless steel

MODELS

Also available in standard version

The W12 pallet stacker is also available in the standard version with 1200kg capacity.

Options

OPTIONS

Available options

Custom forks

PL pallet stacker with quick battery change
PL pallet stacker with quick battery change

OPTIONS

Available options

Custom forks

BATTERIES

Available batteries

Traction battery GEL 2 x 12V 100 Ah
